Electronic filling system with probe technology

• Electronical determination of the fill level via probe
• End of filling after probe signal
• Electropneumatic filling valve
• Two filling speeds

Field of applications: Filling of carbonated and non-carbonated water into glass

Output: Up to 78,000 containers per hour

Foamless filling

• Use of swirl inserts at the filling valve outlet

Maximum filling accuracy

• Krones probe technology
• Turbulence-free change between two filling speeds through the use of membrane technology

Perfect harmony between the pneumatic components and the electronic components

• All processes 100 percent reproducible: no additional installations (e.g. pressure transducer with corresponding electronics) required

High filling stability

• Separation of the pressurisation channel and the snifting channel
• Absolutely dry pressurisation without any aerosol carry-over

Precision and long service life

• Use of special pneumatic components with a significantly higher life cycle than the one of conventional switching valves

Hygienic design

• No installed parts in the tubular ring bowl
• Press-on cam in drip-proof design
• Vacuum pump integrated in the CIP circuit
• Height-adjustable splinter washout system
• Oil-free lift cylinders
• Self-draining surfaces
• Clean pneumatic hosing and electrical wiring
