    Krones VarioSpin
    VarioSpin product deaerator

      The efficient product deaerator

      Foam-free filling of juice products

      You have invested a great deal in order to develop a fruit juice beverage of top quality? You want to be sure that this quality is preserved in the manufacturing and filling processes? Then integrate the Krones product deaerator VarioSpin in your manufacturing process. With VarioSpin you make use of a compact vacuum-assisted deaerator which permits highly effective filling processes without the formation of foam at the filling valve.

      At a glance

      • Deareation tanks with patented swirl inlet
      • Output: 7.5 to 60 m3/h
      • Recovery and return of flavouring through a Venturi nozzle
      • Internal recirculation for a multi-stage deaeration
      • Reduced mixing phases for short change-over times and low product losses
      Brochure Krones VarioSpin
      0.38 MB, .pdf

      Method of operation

      1 Gentle product feed

      • Patented swirl inlet nozzle, which creates an immediate and even product layer on the inner container wall as soon as the product is coming in
      • Turbulent flowing film enables short diffusion paths for the gas bubbles coming from the product
      • The entire tank surface can be used for the deaeration process

      2 Individual adjustment of the vacuum pressure

      • Vacuum pressure adjusted to the infeed temperature and product properties
      • Gentle feed prevents uncontrolled foaming
      • Vacuum pressure can be reduced to the point required for high deaeration performance

      3 Recovery of flavouring losses

      • Recovery of flavouring carry-over in a (multi-stage) condensation step
      • Flavouring return via the Venturi nozzle in the discharging product flow with reliable homogenisation via the product pump
      • Avoidance of flavouring concentrate carry-over during the change-over to other beverages via intelligent backflushing processes
      • Obtaining important flavouring in the beverage at the respective cooling temperature of the condenser


      Simplicity, innovation and function – the factors for the most effective product deaerator on the market


      Water saving

      • Reduced water consumption thanks to intelligent sealing water utilisation in the vacuum pump circuit
      • Only 10 l/h* of water instead of 1,000 l/h

      * Depending on the pump size

      Innovation: patented swirl inlet nozzle

      • Gentle distribution
      • Reduced foaming
      • Product feed independent from the volume flow rate
      • Entire tank as a material exchange surface
      • High gas reduction

      Venturi nozzle

      • Just-in-time return of flavouring with reliable homogenisation via the product pump

      Compact design

      • Minimum of mixing phases
      • No moving parts in the vacuum area
      • Short product dwell time in the system
      • Smallest space requirement on the market

      Efficient flavouring condensation

      • High product quality without the loss of flavouring sensation

      Benefits to you

      The right swirl

      The dissolved gas can be quickly eliminated from the product with the thin product film upon entry into the deaeration container. And the performance of your filling line remains continually at a high level.

      Foam-reduced filling

      The deaeration performance benefits from product which is fed in gently and a turbulent surface. Without foaming, the product can be deaerated highly efficiently.

      Variable product flow

      The technology of the swirl inlet guarantees flexibility in the deaeration performance. You can adjust the product flow at constant deareation rates by up to 50 percent without any dynamic components and high maintenance effort.

      Efficient product change-over conditions

      Due to the smaller tank volume resulting from the efficient product infeed technology, you can achieve up to 50 percent fewer mixing phases during product change-overs.

      Comfortable operation and maintenance

      During the operation of the VarioSpin deaeration module, your employees profit from the ergonomically arranged measurement devices and sensors. Furthermore, the small number of seals and components is a clear advantage in daily operation.

      Flexible during operational changes

      If changes are carried out in your plant, the VarioSpin product deaerator adjusts to them. Since it is modular in design and software concept, the product deaerator can be quickly integrated in new lines or it can be supplemented as a stand-alone solution.
